Production Information

Whether it is our StageRight staging & barricade, our in-house forklifts or our own rigging & lighting packages, the Bryce Jordan Center is equipped to help make your event a successful one.

House Equipment

  • StageRight black Techstage (4’ x 8’ sections)
  • StageRight CC500 Blowthru barricade (black)
  • One 5000lbs forklift (propane)

Lighting

  • ETC IonXE Console
  • 40 Chauvet R2 LED Wash Fixtures
  • 12 Chauvet MK3 Spot Intelligent Light Fixture w/ Gobos
  • 8 Chauvet Force 1 Spot Intelligent Light Fixture w/ Gobos
  • 8 Martin Quantum Profile Intelligent Light Fixture w/ Gobos
  • 24 Martin Mac 101 RGB Intelligent Light Fixture Wash Unit
  • 16 Martin Atomic 3000 DMX Strobe Light
  • 8 JTE Par 36 Audience Blinders
  • Assorted Source 4 Ellipsoidals

Video

  • 72 Chauvet F2 2mm LED Video Panel
    • 3x 6.5' x 11.5' (Left/Center/Right)
    • 2x 10' x 18' (Left/Right)
    • 1x 13' x 23'
  • 2 Chauvet VIP Nova 10-5 Video Processor
  • 4 Chauvet Ground Support Kit
  • ATEM Video Switcher

Audio

PA System:

  • 40 EAW Anya Adaptive PA Modules that can be flown in multiple configurations depending on the event
  • 14 EAW Otto Subwoofers that can be flown or ground stacked depending on the event.
  • 8 EAW JF80 Front Fills

Monitor System:

  • 8 EAW MQ12 Edges
  • 8 Channels of Amplification

Microphones:

  • 8 Shure Axient Wireless Combo Channels
  • Limited Supply of Wired Microphones

Consoles:

  • Midas Pro 2
    • DL251 48in 16out
    • 3 DL155 8in 8out 8aes
  • Midas Pro 2C

Rigging

  • 7 ½ ton hoists
  • 25 1 ton hoists
  • 4 ¼ ton hoists
  • 300’ of 12” box truss
  • 240’ of 20” box truss
  • Assorted steel package

Power

The following is a summary of amp services available in the Bryce Jordan Center.

  • StageLeft: (1) 200A, (1) 400A and (1) 1,000A
  • StageRight: (1) 400A
  • FOH: (1) 800A - This amp service currently has a cable run to StageLeft to provide 400A isolated from the power sources.
  • East Dock: (1) 200A
  • Shore Power: (2) 200A located next to the building, (3) 100A located in the parking lot

Parking and Loading Dock Access

The loading docks for the BJC can be accessed off of Dauer Drive and University Drive  (127 Jordan Center, University Park, PA 16802). There is a gated lot with limited parking. Parking is control by the campus parking office. Permits are required.

The BJC has 3 loading docks available to use, 2 on the West side, closest to University Drive. These are the closest docks to the Event Side of the arena. The third dock, on the East side of the arena is closest to the Kitchen and FOH side of the arena.

Production Personnel should access the building via the Show & Media Entrance next to the west loading dock. A door guard is stationed at that entrance and will request to see credentials before providing access to the building.

On event days, the gated lot is secured by a guard at the gate. No parking is permitted unless permission is provided by BJC Management. To request permission to that lot on an event day, please contact Chad Swires 814-441-1543.
